IGD515EI-34 Images
- Manufacturer: Power Integrations (PI)
- Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 36-DIP Module, 24 Leads
- Description: IC GATE DRVR HI/LOW SIDE MODULE
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IGD515EI-34 Specifications:
- MfrPart.: IGD515EI-34
- Mfr: Power Integrations
- Description: IC GATE DRVR HI/LOW SIDE MODULE
- Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
- Package: Tray
- Series: SCALE™-1
- PartStatus: Active
- DrivenConfiguration: High-Side or Low-Side
- ChannelType: Single
- NumberofDrivers: 1
- GateType: IGBT, N-Channel, P-Channel MOSFET
- Voltage-Supply: 12V ~ 16V
- LogicVoltage-VILVIH: 0.9V, 3.8V
- Current-PeakOutput(SourceSink): 15A, 15A
- InputType: -
- HighSideVoltage-Max(Bootstrap): -
- Rise/FallTime(Typ): 40ns, 40ns
- OperatingTemperature: -40°C ~ 85°C
- MountingType: Through Hole
- Package/Case: 36-DIP Module, 24 Leads
- IGD515EI-34 Power Integrations, IC GATE DRVR HI/LOW SIDE MODULE, Integrated Circuits (ICs)~PMIC - Gate Drivers
