LCS702LG Images
- Manufacturer: Power Integrations (PI)
- Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers Package/Case: 16-SSIP, 13 Leads, Exposed Pad, Formed Leads
- Description: INTEGRATED LLC CONTROLLER
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
LCS702LG Specifications:
- MfrPart.: LCS702LG
- Mfr: Power Integrations
- Description: INTEGRATED LLC CONTROLLER
- Product Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
- Package: Tube
- Series: HiperLCS™
- PartStatus: Active
- OutputConfiguration: Half Bridge
- Applications: General Purpose
- Interface: On/Off
- LoadType: Inductive
- Technology: Power MOSFET
- RdsOn(Typ): 740mOhm
- Current-Output/Channel: -
- Current-PeakOutput: 10.3A
- Voltage-Supply: 11.4V ~ 15V
- Voltage-Load: 11.4V ~ 15V
- OperatingTemperature: -40°C ~ 150°C (TJ)
- Features: Auto Restart, Slew Rate Controlled
- FaultProtection: Current Limiting, Over Temperature, Over Voltage, Short Circuit, UVLO
- MountingType: Through Hole
- Package/Case: 16-SSIP, 13 Leads, Exposed Pad, Formed Leads
- LCS702LG Power Integrations, INTEGRATED LLC CONTROLLER, Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
