LNK501PN Images
- Manufacturer: Power Integrations (PI)
- Category: Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers Package/Case: 8-DIP (0.300, 7.62mm), 7 Leads
- Description: IC OFFLINE SWITCH FLYBACK 8DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
LNK501PN Specifications:
- MfrPart.: LNK501PN
- Mfr: Power Integrations
- Description: IC OFFLINE SWITCH FLYBACK 8DIP
- Product Category: Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers
- Package: Tube
- Series: LinkSwitch®
- PartStatus: Not For New Designs
- OutputIsolation: Isolated
- InternalSwitch(s): Yes
- Voltage-Breakdown: 700V
- Topology: Flyback
- Voltage-StartUp: -
- Voltage-Supply(Vcc/Vdd): -
- DutyCycle: 77%
- Frequency-Switching: 30kHz ~ 42kHz
- Power(Watts): 5.5 W
- FaultProtection: Current Limiting, Open Loop, Over Temperature, Short Circuit
- ControlFeatures: -
- OperatingTemperature: -40°C ~ 150°C (TJ)
- Package/Case: 8-DIP (0.300, 7.62mm), 7 Leads
- LNK501PN Power Integrations, IC OFFLINE SWITCH FLYBACK 8DIP, Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers
