Power Integrations InnoMux chipset for display power supplies consists of an InnoMux controller IC partnered with an InnoSwitch3-MX isolated switcher IC. Click on the image above for more detail on the two devices.
The chipset’s unique single-stage power architecture reduces losses in display applications by increasing overall efficiency in constant-voltage and constant-current LED backlight driver stages by 50% compared to conventional solutions, achieving up to 91% efficiency. TV and display designers can realize over 50% reduction in component count, reducing manufacturing cost and providing an associated improvement in board reliability.
Highlights
● Completely eliminates backlight boost converter and up to 2 buck converters
● 50% reduction in system power conversion losses
- Elimination of losses from Buck and LED backlight boost converters
- Up to 91% efficiency
● InnoSwitch3-MX QR flyback IC
● InnoMux CV and dimmable LED backlight
Do you know more about Power Integrations's product uses, technical documents, and solutions related to InnoMux? Then quickly get in touch with Power Integrations Distributor - NHE!
