SID1181KQ-TL Images
- Manufacturer: Power Integrations (PI)
- Category: Isolators~Isolators - Gate Drivers Package/Case: 16-PowerSOIC (0.350, 8.89mm Width), 15 Leads
- Description: 8A 750V ESOP IGBT T/R
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SID1181KQ-TL Specifications:
- MfrPart.: SID1181KQ-TL
- Mfr: Power Integrations
- Description: 8A 750V ESOP IGBT T/R
- Product Category: Isolators~Isolators - Gate Drivers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: SCALE-iDriver™
- PartStatus: Active
- Technology: Capacitive Coupling
- NumberofChannels: 1
- Voltage-Isolation: 5000Vrms
- CommonModeTransientImmunity(Min): 50kV/µs
- PropagationDelaytpLH/tpHL(Max): 340ns, 330ns
- PulseWidthDistortion(Max): -
- Rise/FallTime(Typ): 465ns, 460ns
- Current-OutputHighLow: 3.6A, 4A
- Current-PeakOutput: 8A
- Voltage-Forward(Vf)(Typ): -
- Current-DCForward(If)(Max): -
- Voltage-OutputSupply: 22V ~ 28V
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 16-PowerSOIC (0.350, 8.89mm Width), 15 Leads
- SID1181KQ-TL Power Integrations, 8A 750V ESOP IGBT T/R, Isolators~Isolators - Gate Drivers
