SID1182K Images
- Manufacturer: Power Integrations (PI)
- Category: Isolators~Isolators - Gate Drivers Package/Case: 16-PowerSOIC (0.350, 8.89mm Width), 15 Leads
- Description: DGTL ISO 5KV GATE DRVR ESOP-R16B
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SID1182K Specifications:
- MfrPart.: SID1182K
- Mfr: Power Integrations
- Description: DGTL ISO 5KV GATE DRVR ESOP-R16B
- Product Category: Isolators~Isolators - Gate Drivers
- Package: Tube
- Series: SCALE-iDriver™
- PartStatus: Active
- Technology: Magnetic Coupling
- NumberofChannels: 1
- Voltage-Isolation: 5000Vrms
- CommonModeTransientImmunity(Min): -
- PropagationDelaytpLH/tpHL(Max): 340ns, 330ns
- PulseWidthDistortion(Max): -
- Rise/FallTime(Typ): 90ns, 81ns
- Current-OutputHighLow: 3.6A, 4A
- Current-PeakOutput: 8A
- Voltage-Forward(Vf)(Typ): -
- Current-DCForward(If)(Max): -
- Voltage-OutputSupply: 22V ~ 28V
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 16-PowerSOIC (0.350, 8.89mm Width), 15 Leads
- SID1182K Power Integrations, DGTL ISO 5KV GATE DRVR ESOP-R16B, Isolators~Isolators - Gate Drivers
SID1182K, Power Integrations authentic parts in stock from Power Integrations authorized distributors, order today, can ship immediately.
