SID1183K Images
- Manufacturer: Power Integrations (PI)
- Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 16-PowerSOIC (0.350, 8.89mm Width), 15 Leads
- Description: IC GATE DRV HI/LO SIDE ESOP-R16B
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SID1183K Specifications:
- MfrPart.: SID1183K
- Mfr: Power Integrations
- Description: IC GATE DRV HI/LO SIDE ESOP-R16B
- Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
- Package: Tube
- Series: SCALE™-1
- PartStatus: Last Time Buy
- DrivenConfiguration: High-Side or Low-Side
- ChannelType: Single
- NumberofDrivers: 2
- GateType: IGBT, N-Channel MOSFET
- Voltage-Supply: 4.75V ~ 5.25V
- LogicVoltage-VILVIH: 0.5V, 3.3V
- Current-PeakOutput(SourceSink): 8A, 48A
- InputType: Inverting
- HighSideVoltage-Max(Bootstrap): -
- Rise/FallTime(Typ): 465ns, 460ns
- OperatingTemperature: -40°C ~ 125°C (TJ)
- MountingType: Surface Mount
- Package/Case: 16-PowerSOIC (0.350, 8.89mm Width), 15 Leads
- SID1183K Power Integrations, IC GATE DRV HI/LO SIDE ESOP-R16B, Integrated Circuits (ICs)~PMIC - Gate Drivers
