TFS764HG Images
- Manufacturer: Power Integrations (PI)
- Category: Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers Package/Case: 16-SSIP, 12 Leads, Exposed Pad, Formed Leads
- Description: IC OFFLIN CONV MULT TOP ESIP-16B
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TFS764HG Specifications:
- MfrPart.: TFS764HG
- Mfr: Power Integrations
- Description: IC OFFLIN CONV MULT TOP ESIP-16B
- Product Category: Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers
- Package: Tube
- Series: HiperTFS®
- PartStatus: Obsolete
- OutputIsolation: Isolated
- InternalSwitch(s): Yes
- Voltage-Breakdown: 530V, 725V
- Topology: Flyback, Forward
- Voltage-StartUp: 12.1 V
- Voltage-Supply(Vcc/Vdd): 11.1V ~ 13.4V
- DutyCycle: 70%
- Frequency-Switching: 66kHz
- Power(Watts): 414 W
- FaultProtection: Current Limiting, Over Temperature, Over Voltage, Short Circuit
- ControlFeatures: EN
- OperatingTemperature: -40°C ~ 150°C (TJ)
- Package/Case: 16-SSIP, 12 Leads, Exposed Pad, Formed Leads
- TFS764HG Power Integrations, IC OFFLIN CONV MULT TOP ESIP-16B, Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers
