TOP256PN Images
- Manufacturer: Power Integrations (PI)
- Category: Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers Package/Case: 8-DIP (0.300, 7.62mm), 7 Leads
- Description: IC OFFLINE SWITCH FLYBACK 8DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TOP256PN Specifications:
- MfrPart.: TOP256PN
- Mfr: Power Integrations
- Description: IC OFFLINE SWITCH FLYBACK 8DIP
- Product Category: Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers
- Package: Tube
- Series: TOPSwitch®-HX
- PartStatus: Active
- OutputIsolation: Isolated
- InternalSwitch(s): Yes
- Voltage-Breakdown: 700V
- Topology: Flyback
- Voltage-StartUp: -
- Voltage-Supply(Vcc/Vdd): -
- DutyCycle: 78%
- Frequency-Switching: 66kHz
- Power(Watts): 34 W
- FaultProtection: Current Limiting, Over Temperature, Over Voltage
- ControlFeatures: -
- OperatingTemperature: -40°C ~ 150°C (TJ)
- Package/Case: 8-DIP (0.300, 7.62mm), 7 Leads
- TOP256PN Power Integrations, IC OFFLINE SWITCH FLYBACK 8DIP, Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers
TOP256PN, Power Integrations authentic parts in stock from Power Integrations authorized distributors, order today, can ship immediately.
